Channels Mode：37/41CH

Light Source
Lamp：LED 1000W
Life time：20000 hours,  Luminous Flux：52000
Power：AC110-240V,50/60Hz
Total power：1300W；PF≥0.95

Opatical System
Output lens size 150mm
Beam angel：5.5-39°,linearzoom
Dimmer :0-100% linear adjustment
If customerneed add extra CRI option lens, there will be one color lens been substitute.

Color Wheels
7 fix color +white+CMY+CTO. CT:3200-6000K

Gobo Wheels
Fixed GOBO:   8 GOBO + white
RotationGOBO:6 GOBO+ white, changeable

Prism System
 4 facet prism, positiveand negative rotation; linear frost function

Control & Screen
Display:3.5inch color LCD display, can reverse 180°
Aperture:mechanical linear aperture, adjustable spot size.
Cut: 4plates. After cut ,the pattern can rotation 180°.
Iris:Disphragm adjustable.
Retrievingmagneto electric positioning system has higher accuracy and reliableperformance.
USBconnector can set DMX address with power and upgrade the software.
Lamp control: electronic bright and blow out, turn off and shut down for 8 seconds,then start the ECO power down mode.

PAN & TILT
Pan：540°，8/16Bit
Tilt ：270°，8/16Bit

Size & Weight
Product size:  482x371.7x870 mm
Carton box: 580x590x1000 mm
Flycaes: 680x705x940 mm
N.W:  42KG
G.W:  75 KG(with flycase 1 in 1)
